Midbass Zevox ZS 6.5AL By Vox Research Specifications: ZEVOX ZS 6.5 AL, 6,5" MIDBASS REFERENCE 6.5'' Midbass SPECIFICATION Electrical Data : • Nominal Impedance (Zn) : 4.0 Ω • DC Resistance (Re) : 3.2 Ω • Maximum Impedance(Zm) : 29,065 Ω • Minimum impedance / at Freq (Zmin) : 4.296 / 214.453 Ω/Hz TS Parameters • Resonance Frequency (fs/fo) : 43.089 / 67.396 Hz • Mechanical Q Factor (Qms) : 3.905 • Electrical Q Factor (Qes) : 0.848 • Total Q Factor (Qts) : 0.697 • Force Factor (BL) : 4,165 T-M • Moving Mass without Air Load (Mmd) : 10.880 g • Moving Mass including Air Load(Mms) : 11,800 g • Suspension Compliance (Cms) : 0.500 m/n • Effective Piston Area(Sd) : 136 c ㎡ • Equivalent Volume (Vas) : 13.309 Ltrs • Reference Efficiency(No) : 0.404 % • Frequency Response(Free Air) : Fo~15k Hz • Sensitivity(1W/1M) : 91.1±3 dB Voice Coil and Magnet Parameters • Voice Coil Diameter : 1.0 Inch • Voice Coil Layer : 2 • Voice Coil Former : Kapton • Voice Coil Wire : SV-Copper • Height of the Gap : 5 mm • Linear Excursion : ±4.3 mm • Material of Magnet : Sr. Ferrite • Diameter of Magnet : 90 mm/pcs • Height of Magnet : 17 mm • Dust Cap : Aluminum • Copper Ring : Copper Power Handling • Rated Input Power : 50 – 100 Watt • Maximum Input Power : 300 Watt Cone & Surround Material • Aluminum Cone with NB-Rubber

Condition

New

Weight

2500g
